Manual Operation
2. Use the numeric (
0
~
9
) keys or “Rotary” (
) knob to set the value.
3. Press “
ENTER
” to confirm.
4. Press “
EXIT
” to return to MAIN PAGE.
This function sets the protection point for Over Power. Once the output power exceeds the
range, it will turn off the output that is OUTPUT = OFF to protect the unit under test.
NOTICE
1. The table below is the power range of OPP.
Model Max. OPP (W)
62012P-xx-xx 1260
62006P-xx-xx 630
Table 3-6 OPP Range
2. When 0 is set for the OPP, it means the function is disabled.
3. The OPP protection point is based on the comparison of calculated power of output
current and remote sense voltage. However, if the power measured by the output terminal
on rear panel is larger than the listed maximum output power in Table 3-6, the system
will still prompt OPP and turn off the output.
When OPP occurs the main page will prompt a protection message as shown below:
V _ S E T = 8 0 .0 0 V I_SET=15.00A O FF
0 0 . 0 0 V
00 . 00A
0 . 0 W
O P P
Figure 3-62
3.3.5.4 FOLDBACK
This function allows users to turn off the output that is OUTPUT = OFF when changing
output mode (CV to CC, or CC to CV) to protect the unit under test.
1. Use “
”, “
” keys to move the cursor to the column to be set as Figure 3-63
shows.
3-39
