Programmable DC Power Supply 62000P Series Operating & Programming Manual
[ P R O T E C T I O N ]
O V P = 88.0V
O C P = 63.0A
O P P = 1260.0W
F O L D B A C K = D I S A B L E
Figure 3-63
2. Use “Rotary” (
) knob to set the protection mode.
There are three options available for selection: DISABLE, CV TO CC and CC TO CV.
1. DISABLE: Ignore the output off function.
2. CV TO CC: Active in CV MODE only. Once the work mode changed to CC
MODE the system will turn off the output to protect the UUT.
3. CC TO CV: Active in CC MODE only. Once the work mode changed to CV
MODE the system will turn off the output to protect the UUT.
When the FOLDBACK option set to CV TO CC or CC TO CV, a selection for DELAY
TIME will prompt beneath for users to set the time delayed for protection after changed
the mode as Figure 3-64 shows.
[ P R O T E C T I O N ]
O V P = 8 8 . 0 V
O C P = 6 3 . 0 A
O P P = 1 2 6 0 . 0 W
F O L D B A C K = C V T O C C
D E L A Y T I M E = 0 . 1 0 S
Figure 3-64
When FOLDBACK protection occurs the main page will prompt a protection message as
shown below:
