Manual Operation
V _ S E T = 8 0 . 0 0 V I _ S E T = 1 5 . 0 0 A C V O N
8 0 . 0 0 V 12 . 00A
9 6 0 . 0 W
V RAGNE = [V LIMIT MIN]V~[V LIMIT MAX]V
Figure 3-18
3. Press “
ENTER
” to confirm.
4. Press “
EXIT
” to return to MAIN PAGE.
3.3.2.2 CURRENT LIMIT SETTING
1. Use “
”, “
” keys to move the cursor to the column to be set.
[ O U T P U T S E T U P ]
V L I M I T : M A X = 8 0 . 0 0 V M I N = 0 0 0 . 0 0 V
I L I M I T : M A X = 1 5 . 0 0 A M I N = 0 0 0 . 0 0 A
V S L E
RA T E = 1 . 00 ( V / mS )
I S L E
RA T E = 1 . 00 ( A / mS )
T T L V A L U E = 0 ( D E C )
< B I N A R Y = 0 0 0 0 0 0 0 0 >
Figure 3-19
2. Use the numeric (
0
~
9
) keys or “Rotary” (
) knob to set the value.
Take example by 62012P-80-60, the output current range is 0~60A, but using this option
can narrow down its range by setting MIN and MAX.
When “
CURRENT
” is pressed to set the output current, the DC Power Supply allows setting
the current within the range of [MIN value ≤ user-defined value ≤ MAX value]. If the
setting exceeds the range, the BUZZER will beep (if BUZZER is set to ON) and the
main screen will prompt a warning message automatically as shown below. In the
meantime, the system will modify the current limit of MIN or MAX automatically.
3-13
To Next Page
