Programmable DC Power Supply 62000P Series Operating & Programming Manual
4. Press “
EXIT
” to return to MAIN PAGE.
This function sets the protection point for Over Current. Once the output current exceeds the
range, it will turn off the output that is OUTPUT = OFF to protect the unit under test.
NOTICE
1. The table below is the current range of OCP.
Model Min. OCP (A) Max. OCP (A)
62000P-xx-xx 1.05 x Io_SET 1.05 x Io_MAX
Table 3-5 OCP Range
2. When 0 is set for the OCP, it means the function is disabled.
When OCP occurs the main page will prompt a protection message as shown below:
V _ S E T = 8 0 . 0 0 V I _ S E T = 1 5 . 0 0 A O F F
0 0 . 0 0 V
00 . 00A
0 . 0 W
O C P
Figure 3-60
3.3.5.3 OPP Protection
1. Use “
”, “
” keys to move the cursor to the column to be set as Figure 3-61
shows.
[ P R O T E C T I O N ]
O V P = 88.0V
O C P = 63.0A
O P P = 1260.0W
F O L D B A C K = D I S A B L E
Figure 3-61
3-38
