Programmable DC Power Supply 62000P Series Operating & Programming Manual
V _ S E T = 8 0 . 0 0 V I _ S E T = 1 5 . 0 0 A C V O N
8 0 . 0 0 V 12 . 00A
9 6 0 . 0 W
I RAGNE = [I LIMIT MIN]A ~ [I LIMIT MAX]A
Figure 3-20
3. Press “
ENTER
” to confirm.
4. Press “
EXIT
” to return to MAIN PAGE.
3.3.2.3 VOLTAGE SLEW RATE
1. Use “
”, “
” keys to move the cursor to the column to be set.
[ O U T P U T S E T U P ]
V L I M I T : M A X = 8 0 . 0 0 V M I N = 0 0 0 . 0 0 V
I L I M I T : M A X = 1 5 . 0 0 A M I N = 0 0 0 . 0 0 A
V S L E
W
RA T E = 1 . 00 ( V / mS )
I S L E
W
RA T E = 1 . 00 ( A / mS )
T T L V A L U E = 0 ( D E C )
< B I N A R Y = 0 0 0 0 0 0 0 0 >
Figure 3-21
2. Use the numeric (
0
~
9
) keys or “Rotary” ( ) knob to set the value.
Take example by 62012P-80-60, the output voltage slew rate is set as Figure 3-22 shows.
The maximum input Slew Rate is 10V/mS and the minimum is 0.01V/mS. The output of
DC Power Supply will follow the slew rate to raise to the set output voltage while the
down slew rate is limited by load.
