Manual Operation
[ S Y S T E M S E T U P ]
G P I B A D D R = 1
R S - 2 3 2 B A U D R A T E = 9 6 0 0
A P G = N O N E
B A C K L I G H T = H I G H
B U Z Z E R = O N
P O W E R O N S T A T U S = D E F A U L T
Figure 3-5
2. Press “
ENTER
” to edit the options in SYSTEM SETUP.
Following introduces the options of SYSTEM SETUP.
3.3.1.1 GPIB ADDRESS
This instrument is available for remote operation. Be sure to set the GPIB address before
using it for remote control.
1. Use “
”, “
” keys to move the cursor to GPIB ADDR column.
2. Use the numeric (
1
~
0
) keys or “Rotary” (
) to set the address.
3. Press “
ENTER
” to confirm.
NOTICE
The address range is 0~30.
3.3.1.2 RS-232 BAUDRATE
This instrument is available for remote operation via RS-232. Be sure to set the RS-232
baudrate before using it for remote control.
1. Use “
”, “
” keys to move the cursor to RS-232 BAUDRATE column.
2. Use “Rotary” (
) knob to set the BAUDRATE.
NOTICE
The RS-232 has 5 baudrates 9600/19200/38400/57600/115200 for setting.
3-5
