Manual Operation
3.3.3.4.2 Setting SYSTEM SETUP for Series
The option POWER ON STATUS in SYSTEM SETUP must set to USER DEFINIITION
when connected in series along with the output voltage. The voltage set increases following
the number connected in series and for easy identification it is indicated by ΣV as Figure
3-39 shows.
[S
STE
SE
U
]
G P I B A D DR = 1
R S - 2 3 2 B A U D R
T
=9600
A P G = NONE
B A C
L I G HT = HIGH
B U Z Z E
= ON
P O W ER O N S T A
U
= USER DE F I N I T I O N
Σ
V = 4 0 0 . 0 0 V I = 4 0 . 0 0 A O U T P U T = O
Figure 3-39
3.3.3.4.3 Setting OUTPUT SETUP for Series
The V LIMIT MAX in OUTPUT SETUP of MASTER for series connection will increase
following the number connected in series. It is indicated by ΣV LIMIT MAX: for easy
identification as Figure 3-40 shows. Furthermore, the setting range of V SLEW RATE will
increase following the number connected in series too.
[OUTPUT S E T U P ]
Σ
V L I M I T : M A X= 80 .00V M I N= 00 0 . 0 0 V
I L I M I T : M A X = 1 5 . 0 0 A M I N = 0 0 0 . 0 0 A
Σ
V S L E W R A T E = 1 . 0 0 ( V / m S )
I S L E W R A T E = 1 . 0 0 ( A / m S )
T T L V A L U E = 0 ( D E C )
< B I N A
= 000000 0 0 >
Figure 3-40
3.3.3.4.4 Setting PROTECTION for Series
The OVP and OPP in PROTECTION of MASTER for series connection will increase
following the number connected in series. It is indicated by ΣOVP and ΣOPP for easy
identification as Figure 3-41 shows.
3-27
