Manual Operation
(10) Press ENTER will perform 50A calibration. The system will set the output current to
50.00A automatically and the cursor will stop at position [4] as Figure 3-94 shows. Input
the current (4 digits after decimal point) read by Current Shunt (DVM) and press
“
ENTER
” to confirm.
[ C U R R E N T S E T T I N G C A L I B R A T I O N ]
S H O R T O U T P U T T E R M I N A L A N D P R E S S [ E N T E R ]
S E T T I N G O U T P U T C U R R E N T 2 0 . 0 A
A C T U A L O U T P U T C U R R E N T = 1 9 . 9 9 2 2 A
S E T T I N G O U T P U T C U R R E N T 5 0 . 0 A
A C T U A L O U T P U T C U R R E N T = 4 9 . 9 8 1 2 A
]4[
Figure 3-94
(11) The current calibration is done once the above actions are completed. Turn off the DC
Power Supply output and press “
SAV E
” and “
ENTER
”to save the calibrated data as Figure
3-95 shows, or press “
EXIT
” to return to Calibration page without saving.
S
E=YES
Figure 3-95
(12) Press “
EXIT
” to return to MAIN PAGE.
Improper shunt range selection may cause damage to the current shunt.
NOTICE
The calibration point may be different for other models (non 62012P-80-60), please operate it
following the instructions displayed.
3-57
