Chapter 29 Configuring IP Unicast Routing
Configuring Multi-VRF CE
Router(config)# ip cef
Router(config)# interface Loopback1
Router(config-if)# ip vrf forwarding v1
Router(config-if)# ip address 3.3.1.3 255.255.255.0
Router(config-if)# exit
Router(config)# interface Loopback2
Router(config-if)# ip vrf forwarding v2
Router(config-if)# ip address 3.3.2.3 255.255.255.0
Router(config-if)# exit
Router(config)# interface gigabitthernet0.10
Router(config-if)# encapsulation dot1q 10
Router(config-if)# ip vrf forwarding v1
Router(config-if)# ip address 38.0.0.3 255.255.255.0
Router(config-if)# exit
Router(config)# interface gigabitethernet0.20
Router(config-if)# encapsulation dot1q 20
Router(config-if)# ip vrf forwarding v2
Router(config-if)# ip address 83.0.0.3 255.255.255.0
Router(config-if)# exit
Router(config)# router bgp 100
Router(config-router)# address-family ipv4 vrf v2
Router(config-router-af)# neighbor 83.0.0.8 remote-as 800
Router(config-router-af)# neighbor 83.0.0.8 activate
Router(config-router-af)# network 3.3.2.0 mask 255.255.255.0
Router(config-router-af)# exit
Router(config-router)# address-family ipv4 vrf vl
Router(config-router-af)# neighbor 38.0.0.8 remote-as 800
Router(config-router-af)# neighbor 38.0.0.8 activate
Router(config-router-af)# network 3.3.1.0 mask 255.255.255.0
Router(config-router-af)# end
Displaying Multi-VRF CE Status
You can use the privileged EXEC commands in Table 29-15 to display information about multi-VRF CE
configuration and status.
For more information about the information in the displays, refer to the Cisco IOS Switching Services
Command Reference, Release 12.2.
Table 29-15 Commands for Displaying Multi-VRF CE Information
Command Purpose
show ip protocols vrf vrf-name Display routing protocol information associated
with a VRF.
show ip route vrf vrf-name [connected] [protocol [as-number]] [list]
[mobile] [odr] [profile] [static] [summary] [supernets-only]
Display IP routing table information associated
with a VRF.
show ip vrf [brief | detail | interfaces] [vrf-name] Display information about the defined VRF
instances.
