32-24
Cisco ME 3800X and 3600X Switch Software Configuration Guide
OL-23400-01
Chapter 32 Configuring Ethernet OAM, CFM, and E-LMI
Setting Up and Configuring Ethernet OAM
Setting Up and Configuring Ethernet OAM
• Default Ethernet OAM Configuration, page 32-24
• Ethernet OAM Configuration Guidelines, page 32-24
• Enabling Ethernet OAM on an Interface, page 32-24
• Enabling Ethernet OAM Remote Loopback, page 32-25
• Configuring Ethernet OAM Link Monitoring, page 32-26
• Configuring Ethernet OAM Remote Failure Indications, page 32-29
• Configuring Ethernet OAM Templates, page 32-29
Default Ethernet OAM Configuration
Ethernet OAM is disabled on all interfaces.
When Ethernet OAM is enabled on an interface, link monitoring is automatically turned on.
Remote loopback is disabled.
No Ethernet OAM templates are configured.
Ethernet OAM Configuration Guidelines
• The switch does not support monitoring of egress frames sent with cyclic redundancy code (CDC)
errors. The ethernet oam link-monitor transmit crc interface-configuration or
template-configuration commands are visible but are not supported on the switch. The commands
are accepted, but are not applied to an interface.
• For a remote failure indication, the switch does not generate Link Fault or Critical Event OAM
PDUs. However, if these PDUs are received from a link partner, they are processed. The switch
supports generating and receiving Dying Gasp OAM PDUs when Ethernet OAM is disabled, the
interface is shut down, the interface enters the error-disabled state, or the switch is reloading. The
switch can also generate and receive Dying Gasp PDUs based on loss of power. The PDU includes
a reason code to indicate why it was sent.
• The switch does not support Ethernet OAM on ports that belong to an EtherChannel.
Enabling Ethernet OAM on an Interface
Beginning in privileged EXEC mode, follow these steps to enable Ethernet OAM on an interface:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Define an interface to configure as an OAM interface, and
enter interface configuration mode.
Step 3
ethernet oam Enable Ethernet OAM on the interface.
