Cisco 3845 - Security Bundle Router Software Guide

32-11
Cisco ME 3800X and 3600X Switch Software Configuration Guide
OL-23400-01
Chapter 32 Configuring Ethernet OAM, CFM, and E-LMI
Configuring Ethernet CFM
Use the no form of each command to remove a configuration or to return to the default settings.
Configuring Static Remote MEP
Beginning in privileged EXEC mode, follow these steps to configure Ethernet CFM static remote MEP:
Step 4
service {ma-name | ma-number | vpn-id vpn} {vlan
vlan-id}
Define a customer service maintenance association name
or number or VPN ID to be associated with the domain, and
a VLAN ID, and enter ethernet-cfm-service configuration
mode.
• ma-name—a string of no more than 100 characters that
identifies the MAID.
• ma-number—a value from 0 to 65535.
• vpn-id vpn—enter a VPN ID as the ma-name.
• vlan vlan-id—VLAN range is from 1 to 4094. You
cannot use the same VLAN ID for more than one
domain at the same level.
Step 5
mep mpid identifier Define the MEP maintenance end point identifier in the
domain and service. The range is 1 to 4094.
Step 6
end Return to privileged EXEC mode.
Step 7
ethernet cfm mep crosscheck {enable | disable}
domain domain-name {vlan {vlan-id | any} | port}
Enable or disable CFM crosscheck for one or more VLANs
or a port MEP in the domain.
• domain domain-name—Specify the name of the
created domain.
• vlan {vlan-id | any}—Enter the service provider
VLAN ID or IDs as a VLAN-ID (1 to 4094), a range of
VLAN-IDs separated by a hyphen, or a series of
VLAN IDs separated by comma. Enter any for any
VLAN.
• port—Identify a port MEP.
Step 8
show ethernet cfm maintenance-points remote
crosscheck
Verify the configuration.
Step 9
show ethernet cfm errors [configuration] Enter this command after you enable CFM crosscheck to
display the results of the crosscheck operation. Enter the
configuration keyword to display the configuration error
list.
Step 10
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
ethernet cfm domain domain-name level level-id Define a CFM domain, set the domain level, and enter
ethernet-cfm configuration mode for the domain. The
maintenance level number range is 0 to 7.
