Cisco ME 3800X and 3600X Switch Software Configuration Guide
OL-23400-01
Chapter 31 Configuring Cisco IOS IP SLAs Operations
Monitoring IP SLAs Operations
To disable the IP SLAs operation, enter the no ip sla operation-number global configuration command.
This example shows how to configure an ICMP echo IP SLAs operation:
Switch(config)# ip sla 12
Switch(config-ip-sla)# icmp-echo 172.29.139.134
Switch(config-ip-sla-echo)# frequency 30
Switch(config-ip-sla-echo)# exit
Switch(config)# ip sla schedule 5 start-time now life forever
Switch(config)# end
Switch# show ip sla configuration 22
IP SLAs, Infrastructure Engine-II.
Entry number: 12
Owner:
Tag:
Type of operation to perform: echo
Target address: 2.2.2.2
Source address: 0.0.0.0
Request size (ARR data portion): 28
Operation timeout (milliseconds): 5000
Type Of Service parameters: 0x0
Verify data: No
Vrf Name:
Schedule:
Operation frequency (seconds): 60
Next Scheduled Start Time: Pending trigger
Group Scheduled : FALSE
Randomly Scheduled : FALSE
Life (seconds): 3600
Entry Ageout (seconds): never
Recurring (Starting Everyday): FALSE
Status of entry (SNMP RowStatus): notInService
Threshold (milliseconds): 5000
Distribution Statistics:
Number of statistic hours kept: 2
Number of statistic distribution buckets kept: 1
Statistic distribution interval (milliseconds): 20
History Statistics:
Number of history Lives kept: 0
Number of history Buckets kept: 15
History Filter Type: None
Enhanced History:
Monitoring IP SLAs Operations
Use the User EXEC or Privileged EXEC commands in Table 31-1 to display IP SLAs operations
configuration and results.
Step 8
show ip sla configuration
[operation-number]
(Optional) Display configuration values including all defaults for all IP SLAs
operations or a specified operation.
Step 9
copy running-config
startup-config
(Optional) Save your entries in the configuration file.
Command Purpose
