32-17
Cisco ME 3800X and 3600X Switch Software Configuration Guide
OL-23400-01
Chapter 32 Configuring Ethernet OAM, CFM, and E-LMI
Configuring Ethernet CFM
Step 3
ethernet echo mpid identifier domain domain-name
vlan vlan-id
or
ethernet jitter mpid identifier domain domain-name
vlan vlan-id [interval interpacket-interval]
[num-frames number-of frames transmitted]
Configure the IP SLAs operation as an echo (ping) or jitter
operation, and enter IP SLAs Ethernet echo configuration
mode.
• Enter echo for a ping operation or jitter for a jitter
operation.
• For mpid identifier, enter a maintenance endpoint
identifier. The identifier must be unique for each
VLAN. The range is 1 to 4094.
• For domain domain-name, enter the CFM domain
name.
• For vlan vlan-id, the VLAN range is from 1 to 4095.
• (Optional—for jitter only) Enter the interval between
sending of jitter packets.
• (Optional—for jitter only) Enter the num-frames and
the number of frames to be sent.
Step 4
cos cos-value (Optional) Set a class of service value for the operation.
Step 5
frequency seconds (Optional) Set the rate at which the IP SLAs operation
repeats. The range is from 1 to 604800 seconds; the default
is 60 seconds.
Step 6
history history-parameter (Optional) Specify parameters for gathering statistical
history information for the IP SLAs operation.
Step 7
owner owner-id (Optional) Configure the SNMP owner of the IP SLAs
operation.
Step 8
request-data-size bytes (Optional) Specify the protocol data size for an IP SLAs
request packet. The range is from 0 to the maximum size
allowed by the protocol being used; the default is 66 bytes.
Step 9
tag text (Optional) Create a user-specified identifier for an IP SLAs
operation.
Step 10
threshold milliseconds (Optional) Specify the upper threshold value in
milliseconds (ms0 for calculating network monitoring
statistics. The range is 0 to 2147483647; the default is
5000.
Step 11
timeout milliseconds (Optional) Specify the amount of time in ms that the IP
SLAs operation waits for a response from its request
packet. The range is 0 to 604800000; the default value is
5000.
Step 12
exit Return to global configuration mode.
Command Purpose
