32-19
Cisco ME 3800X and 3600X Switch Software Configuration Guide
OL-23400-01
Chapter 32 Configuring Ethernet OAM, CFM, and E-LMI
Configuring Ethernet CFM
Step 3
type echo domain domain-name vlan vlan-id
[exclude-mpids mp-ids]
or
type jitter domain domain-name vlan vlan-id
[exclude-mpids mp-ids] [interval
interpacket-interval] [num-frames number-of frames
transmitted]
Configure the automatic Ethernet operation to create echo
(ping) or jitter operation and enter IP SLAs Ethernet echo
configuration mode.
• Enter type echo for a ping operation or type jitter for
a jitter operation.
• For mpid identifier, enter a maintenance endpoint
identifier. The range is 1 to 4094.
• For domain domain-name, enter the CFM domain
name.
• For vlan vlan-id, the VLAN range is from 1 to 4095.
• (Optional) Enter exclude-mpids mp-ids to exclude the
specified maintenance endpoint identifiers.
• (Optional—for jitter only) Enter the interval between
sending of jitter packets.
• (Optional—for jitter only) Enter the num-frames and
the number of frames to be sent.
Step 4
cos cos-value (Optional) Set a class of service value for the operation.
Step 5
owner owner-id (Optional) Configure the SNMP owner of the IP SLAs
operation.
Step 6
request-data-size bytes (Optional) Specify the protocol data size for an IP SLAs
request packet. The range is from 0 to the maximum size
allowed by the protocol being used; the default is 66 bytes.
Step 7
tag text (Optional) Create a user-specified identifier for an IP SLAs
operation.
Step 8
threshold milliseconds (Optional) Specify the upper threshold value in
milliseconds for calculating network monitoring statistics.
The range is 0 to 2147483647; the default is 5000.
Step 9
timeout milliseconds (Optional) Specify the amount of time in milliseconds that
the IP SLAs operation waits for a response from its request
packet. The range is 0 to 604800000; the default value is
5000.
Step 10
exit Return to global configuration mode.
Command Purpose
