Cisco 7800 Series Administrator's Guide

Remove the Phone from the Non-Lockable Wall Mount
The wall mounting plate contains two tabs to lock the plate into the phone bracket. The following figure shows
the location and shape of the tabs.
Figure 27: Tab Location
To remove the phone and mounting plate from the wall bracket, you must disengage these tabs.
Before You Begin
You require two screwdrivers or metal rods.
Cisco IP Phone 7800 Series Administration Guide for Cisco Unified Communications Manager
89
Non-Lockable Wall Mount Components for 7861

Cisco 7800 Series Specifications

General

Wireless	No
Video Support	No
PoE	Yes, 802.3af/at
Audio Codec Support	G.711, G.722, G.729, iLBC
Network Protocols	SIP, SDP, IPv4, IPv6, UDP, TCP, DNS, TFTP, HTTP, HTTPS, DHCP
Security Features	802.1X, TLS, SRTP
Power Options	PoE
Headset Port	3.5mm
Buttons	Line keys, navigation cluster, softkeys, mute, speakerphone, headset, volume control
Bluetooth	No
Ethernet Switch	Yes, 2-port 10/100/1000
USB Port	Yes, for headset (7875)
