Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Overview of Options Configurable from a Phone
4-6
Cisco Unified IP Phone 7906G and 7911G Administration Guide for Cisco Unified CallManager 5.1
OL-11515-01
Note There are several options on the Network Configuration menu and on the Device
Configuration Menu that are for display only or that you can configure from
Cisco
Unified CallManager. These options are also described in the “Network
Configuration Menu” section on page 4-7 and the or the “Device Configuration
Menu” section on page 4-15.
Ta b l e 4-1 Network Configuration Menu Settings
Category Description
Network Configuration Menu
Option
DHCP settings Dynamic Host Configuration Protocol (DHCP)
automatically assigns IP address to devices
when you connect them to the network.
Cisco
Unified IP Phones enable DHCP by
default.
DHCP Enabled
DHCP Address Released
IP settings If you do not use DHCP in your network, you
can make IP settings manually.
Domain Name
IP Address
Subnet Mask
Default Router 1-5
DNS Server 1-5
TFTP settings If you do not use DHCP to direct the phone to
a TFTP server, you must manually assign a
TFTP server. You can also assign an alternative
TFTP server to use instead of the one assigned
by DHCP.
TFTP Server 1
Alternate TFTP
TFTP Server 2
VLAN settings Admin. VLAN ID allows you to change the
administrative VLAN used by the phone. PC
VLAN allows the phone to interoperate with
third-party switches that do not support a voice
VLAN.
Admin. VLAN ID
PC VLAN (applies to 7911G
only)
Port settings Allow you to set the speed and duplex of the
network and access ports.
SW Port Configuration
PC Port Configuration (applies
to 7911G only)
