Cisco 7906G Administration Guide

Chapter 7 Viewing Model Information, Status, and Statistics on the Cisco Unified IP Phone
Status Menu
7-14
Cisco Unified IP Phone 7906G and 7911G Administration Guide for Cisco Unified CallManager 5.1
OL-11515-01
Network Statistics Screen
The Network Statistics screen displays information about the phone and network
performance.
To display the Network Statistics screen, follow these steps:
Procedure
Step 1 Press the Applications Menu button.
Step 2 Select Settings.
TFTP timeout TFTP server did not respond. • Network is busy—The errors should
resolve themselves when the network
load reduces.
• No network connectivity between the
TFTP server and the phone—Verify the
network connections.
• TFTP server is down—Check
configuration of TFTP server.
Timed Out Supplicant attempted 802.1X
transaction but timed out to
due the absence of an
authenticator.
Authentication typically times out if 802.1X
is not configured on the switch.
For more information, see the “802.1X
Authentication and Status” section on
page 4-36.
Ve r s i o n e r ro r The name of the phone load
file is incorrect.
Make sure that the phone load file has the
correct name.
XmlDefault.cnf.xml,
or .cnf.xml
corresponding to the
phone device name
Name of the configuration file. None. This is an informational message
indicating the name of the configuration file
for the phone.
Table 7-2 Status Messages on the Cisco Unified IP Phone 7906G and 7911G (continued)
Message Description Possible Explanation and Action
