Chapter 3 Setting Up the Cisco Unified IP Phone
Installing the Cisco Unified IP Phone
3-14
Cisco Unified IP Phone 7906G and 7911G Administration Guide for Cisco Unified CallManager 5.1
OL-11515-01
Figure 3-4 Cisco IP Phone Model 7911G Cable Connections
Related Topics
• Before You Begin, page 3-2
• Mounting the Phone to a Wall, page 3-15
• Configuring Startup Network Settings, page 3-16
1
Network port (10/100 SW)
4
DC Adapter port (DC48V)
2
Access port (10/100 PC)
5
AC-to-DC power supply
3
Handset port
6
AC power cord
3
2
4
6
5
1
91638
