8-15
Cisco Unified IP Phone 7906G and 7911G Administration Guide for Cisco Unified CallManager 5.1
OL-11515-01
Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Streaming Statistics
Streaming Statistics
A Cisco Unified IP Phone can stream information to and from up to three devices
simultaneously. A phone streams information when it is on a a call or running a
service that sends or receives audio or data.
The streaming statistics areas on a phone web page provide information about the
streams. Most calls use only one stream (Stream 1), but some calls use two or
three stream. For example, a barged call uses Stream 1 and Stream 2.
To display a Streaming Statistics area, access the web page for the phone as
described in the
“Accessing the Web Page for a Phone” section on page 8-2, and
then click the Stream 1, the Stream 2, or the Stream 3 hyperlink.
Table 8-5 describes the items in the Streaming Statistics areas.
Ta b l e 8-5 Streaming Statistics Area Items
Item Description
Remote Address IP address and UDP port of the destination of the
stream.
Local Address IP address and UPD port of the phone.
Start Time Internal time stamp indicating when
Cisco
Unified CallManager requested that the phone
start transmitting packets.
Stream Status Indication of whether streaming is active.
Host Name Unique, fixed name that is automatically assigned to
the phone based on its MAC address.
Sender Packets Total number of RTP data packets transmitted by the
phone since starting this connection. The value is 0 if
the connection is set to receive only mode.
Sender Octets Total number of payload octets transmitted in RTP data
packets by the phone since starting this connection.
The value is 0 if the connection is set to receive only
mode.
Sender Codec Type of audio encoding used for the transmitted
stream.
