8-11
Cisco Unified IP Phone 7906G and 7911G Administration Guide for Cisco Unified CallManager 5.1
OL-11515-01
Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Network Statistics
Network Statistics
These network statistics areas on a phone web page provide information about
network traffic on the phone:
• Ethernet Information area—Displays information about Ethernet traffic.
Table 8-3 describes the items in this area.
• Access area—Displays information about network traffic to and from the PC
port on the phone.
Table 8-4 describes the items in this area. (applies to 7911G
only)
• Network area—Displays information about network traffic to and from the
network port on the phone.
Table 8-4 describes the items in this area.
To display a network statistics area, access the web page for the phone as
described in the
“Accessing the Web Page for a Phone” section on page 8-2, and
then click the Ethernet Information, the Access, and or the Network hyperlink.
Voice VLAN Enabled
(applies to 7911G only)
Indicates whether the phone allows a device attached
to the PC port to access the Voice VLAN.
Auto Line Select
Enabled
Indicates whether the phone shifts the call focus to
incoming calls on all lines.
DSCP for Call Control DSCP IP classification for call control signaling.
DSCP for
Configuration
DSCP IP classification for any phone configuration
transfer.
DSCP for Services DSCP IP classification for phone-based services.
Security Mode Displays the security mode that is set for the phone.
Web Access Enabled Indicates whether web access is enabled (Yes) or
disabled (No) for the phone.
Span to PC Port
(applies to 7911G only)
Indicates whether the phone will forward packets
transmitted and received on the network port to the
access port.
PC VLAN (applies to
7911G only)
VLAN used to identify and remove 802.1P/Q tags
from packets sent to the PC
Table 8-2 Network Configuration Area Items (continued)
Item Description
