Cisco 7906G Administration Guide

7-3
Cisco Unified IP Phone 7906G and 7911G Administration Guide for Cisco Unified CallManager 5.1
OL-11515-01
Chapter 7 Viewing Model Information, Status, and Statistics on the Cisco Unified IP Phone
Status Menu
Status Menu
The Status menu contains the following options, which provide information about
the phone and its operation:
• Status Messages—Displays the Status Messages screen, which shows a log of
important system messages. For more information, see the
“Status Messages
Screen” section on page 7-4.
• Network Statistics—Displays the Network Statistics screen, which shows
Ethernet traffic statistics. For more information, see the
“” section on
page 7-5.
• Firmware Versions—Displays the Firmware Versions screen, which shows
information about the firmware running on the phone. For more information,
see the
“Firmware Versions Screen” section on page 7-16.
• 802.1X Authentication Status—Displays the time-stamped authentication
successes and failures. For more information, see the
“802.1X Authentication
Screen” section on page 7-17.
To display the Status menu, press the Menu button and then select Settings >
Status.
To exit the Status menu, press the Exit softkey.
LSC Indicates whether a locally significant
certificate (used for the security
features) is installed on the phone (Yes)
or is not installed on the phone (No)
For information about how to manage the
LSC for your phone, refer to the “Using
the Certificate Authority Proxy Function”
section in Cisco Unified CallManager
Security Guide.
Call Control
Protocol
Displays the call control protocol for
the phone, Skinny Client Control
Protocol (SCCP).
See the “Using Cisco Unified IP Phones
with Different Protocols” section on
page 2-16.
Table 7-1 Model Information
Option Description To Change
