Chapter 3 Setting Up the Cisco Unified IP Phone
Installing the Cisco Unified IP Phone
Figure 3-3 Cisco Unified IP Phone Model 7906G Cable Connections
1
Network port (10/100 SW)
4
AC-to-DC power supply
2
Handset port
5
AC power cord
3
DC Adapter port (DC48V)
10/100 SW
2
5
4
1
3
