Cisco 7906G Administration Guide

7-17
Cisco Unified IP Phone 7906G and 7911G Administration Guide for Cisco Unified CallManager 5.1
OL-11515-01
Chapter 7 Viewing Model Information, Status, and Statistics on the Cisco Unified IP Phone
Status Menu
802.1X Authentication Screen
The 802.1X Authentication screen displays time-stamped 802.1X authentication
failures and successes.
To display the Firmware Version screen, follow these steps:
Procedure
Step 1 Press the Applications Menu button.
Step 2 Select Settings. > Status.
Step 3 Select 802.1X Authentication.
To exit the 802.1X Authentication screen, press the Exit softkey.
Table 7-5 explains the information that appears in the 8021X Authentication
screen.
Ta b l e 7-4 Firmware Version Information
Item Description
Load File Load file running on the phone
App Load ID Identifies the JAR file running on the phone
JVM Load ID Identifies the Java Virtual Machine (JVM) running
on the phone
OS Load ID Identifies the operating system running on the phone
Boot Load ID Identifies the factory-installed load running on the
phone
