DescriptionItem
The main component of Security by Default. Trust
Verification Services (TVS) enables Cisco Unified
IP Phones to authenticate application servers, such as
EM services, directory, and MIDlet, during HTTPS
establishment.
TVS
The name of the TFTP Server used by the phone.TFTP Server
Synchronizes the ports to the lower speed which
eliminates packet loss.
Automatic Port Synchronization
Allows the administrator to configure the speed and
function of the Cisco Desktop Collaboration
Experience table port remotely by using Cisco Unified
Communications Manager Administration.
Switch Port Remote Configuration
Indicates if remote port configuration of the speed
and duplex mode for the PC port is enabled or
disabled.
PC Port Remote Configuration
Displays the IP addressing mode that is available on
the phone.
IP Addressing Mode
Indicates the IP address version that the phone uses
during signaling with Cisco Unified Communications
Manager when both IPv4 and IPv6 are both available
on the phone.
IP Preference Mode Control
Indicates that for media the device uses an IPv4
address to connect to the Cisco Unified
Communications Manager.
IP Preference Mode For Media
Displays whether the auto configuration is enabled or
disabled on the phone.
IPv6 Auto Configuration
Verifies the uniqueness of new unicast IPv6 addresses
before the addresses are assigned to interfaces.
IPv6 DAD
Indicates if the phone accepts the redirect messages
from the same router that is used for the destination
number.
IPv6 Accept Redirect Message
Indicates that the phone sends an Echo Reply message
in response to an Echo Request message sent to an
IPv6 address.
IPv6 Reply Multicast Echo Request
Used to optimize installation time for phone firmware
upgrades and off load the WAN by storing images
locally, negating the need to traverse the WAN link
for each phone's upgrade.
IPv6 Load Server
Cisco IP Conference Phone 8832 Administration Guide for Cisco Unified Communications Manager
143
Cisco IP Conference Phone Troubleshooting
Network Setup Web Page

Cisco 8832 Specifications

General

Control type	Buttons
Display type	LCD
Product type	IP conference phone
Voice codecs	G.711a, G.711u, G.722, G.729A, G.729ab, OPUS, iLBC
Certification	CE Markings per directives 2014/30/EU and 2014/53/EU and 2014/35/EU \u2028 \u2028 UL 60950 Second Edition \u2028 CAN/CSA-C22.2 No. 60950 Second Edition \u2028 EN 60950 Second Edition (including A11 and A12) IEC 60950 Second Edition (including A11 and A12) EN 60950-1 IEC 60950-1 AS/NZS 60950.1 47CFR Part 15 (CFR 47) Class B AS/NZS CISPR32 Class B \u2028 CISPR32 \u2028Class B EN55032 \u2028 Class B EN 300 386 ICES003 Class B \u2028 VCCI Class B \u2028 EN61000-3-2 \u2028 EN61000-3-3 \u2028 EN61000-4-2 IEC61000-4-2 EN61000-4-3 IEC61000-4-3 EN61000-4-6 IEC61000-4-6 KN22 Class B \u2028 EN55024 \u2028 CISPR24 \u2028 KN24 Armadillo Light AS/ACIF S004 NZPTC220
Product color	Charcoal
Frequency range	100 - 20000 Hz
Built-in display	Yes
Display diagonal	3.9 \
Languages support	ARA, BUL, CAT, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Display resolution	480 x 128 pixels
Security algorithms	EAP-FAST, EAP-TLS, SHA-256, SSH
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4, IPv6, SIP, SDP, UDP, DHCP, GARP, TFTP, HTTPS, RTP, RTCP, Cisco Discovery Protocol, LLDP
Cables included	USB
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %
USB connector type	USB Type-C
RJ-45 ports quantity	1

Weight and Dimensions

Width	278 mm
Height	61 mm
Weight	1850 g
