Cisco 8832 Administration Guide

Corporate Directory Setup 117
Personal Directory Setup 117
User Personal Directory Entries Setup 118
Download Cisco IP Phone Address Book Synchronizer 118
Cisco IP Phone Address Book Synchronizer Deployment 119
Install Synchronizer 119
Set Up Synchronizer 119
Cisco IP Conference Phone Troubleshooting 121
PART IV
Monitoring Phone Systems 123
CHAPTER 11
Monitoring Phone Systems Overview 123
Cisco IP Phone Status 123
Display the Phone Information Window 124
Display the Status Menu 124
Display the Status Messages Window 124
Display the Network Statistics Window 131
Display the Call Statistics Window 134
Cisco IP Phone Web Page 136
Access the Phone Web Page 136
Device Information Web Page 137
Network Setup Web Page 138
Ethernet Information Web Page 144
Network Web Pages 145
Console Logs, Core Dumps, Status Messages, and Debug Display Web Pages 147
Streaming Statistics Web Page 147
Streaming Statistics Web Page 150
Request Information from the Phone in XML 153
Sample CallInfo Output 153
Sample LineInfo Output 154
Sample ModeInfo Output 155
Phone Troubleshooting 157
CHAPTER 12
General Troubleshooting Information 157
Cisco IP Conference Phone 8832 Administration Guide for Cisco Unified Communications Manager
vii
Contents

Cisco 8832 Specifications

General

Control type	Buttons
Display type	LCD
Product type	IP conference phone
Voice codecs	G.711a, G.711u, G.722, G.729A, G.729ab, OPUS, iLBC
Certification	CE Markings per directives 2014/30/EU and 2014/53/EU and 2014/35/EU \u2028 \u2028 UL 60950 Second Edition \u2028 CAN/CSA-C22.2 No. 60950 Second Edition \u2028 EN 60950 Second Edition (including A11 and A12) IEC 60950 Second Edition (including A11 and A12) EN 60950-1 IEC 60950-1 AS/NZS 60950.1 47CFR Part 15 (CFR 47) Class B AS/NZS CISPR32 Class B \u2028 CISPR32 \u2028Class B EN55032 \u2028 Class B EN 300 386 ICES003 Class B \u2028 VCCI Class B \u2028 EN61000-3-2 \u2028 EN61000-3-3 \u2028 EN61000-4-2 IEC61000-4-2 EN61000-4-3 IEC61000-4-3 EN61000-4-6 IEC61000-4-6 KN22 Class B \u2028 EN55024 \u2028 CISPR24 \u2028 KN24 Armadillo Light AS/ACIF S004 NZPTC220
Product color	Charcoal
Frequency range	100 - 20000 Hz
Built-in display	Yes
Display diagonal	3.9 \
Languages support	ARA, BUL, CAT, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Display resolution	480 x 128 pixels
Security algorithms	EAP-FAST, EAP-TLS, SHA-256, SSH
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4, IPv6, SIP, SDP, UDP, DHCP, GARP, TFTP, HTTPS, RTP, RTCP, Cisco Discovery Protocol, LLDP
Cables included	USB
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %
USB connector type	USB Type-C
RJ-45 ports quantity	1

Weight and Dimensions

Width	278 mm
Height	61 mm
Weight	1850 g
