Cisco ASA Series User Manual

1-19
Cisco ASA Series CLI Configuration Guide
Chapter 1 Configuring a Service Policy Using the Modular Policy Framework
Configuration Examples for Modular Policy Framework
Applying Inspection and QoS Policing to HTTP Traffic
In this example (see Figure 1-1), any HTTP connection (TCP traffic on port 80) that enters or exits the
ASA through the outside interface is classified for HTTP inspection. Any HTTP traffic that exits the
outside interface is classified for policing.
Figure 1-1 HTTP Inspection and QoS Policing
See the following commands for this example:
hostname(config)# class-map http_traffic
hostname(config-cmap)# match port tcp eq 80
hostname(config)# policy-map http_traffic_policy
hostname(config-pmap)# class http_traffic
hostname(config-pmap-c)# inspect http
hostname(config-pmap-c)# police output 250000
hostname(config)# service-policy http_traffic_policy interface outside
Applying Inspection to HTTP Traffic Globally
In this example (see Figure 1-2), any HTTP connection (TCP traffic on port 80) that enters the ASA
through any interface is classified for HTTP inspection. Because the policy is a global policy, inspection
occurs only as the traffic enters each interface.
Figure 1-2 Global HTTP Inspection
See the following commands for this example:
hostname(config)# class-map http_traffic
hostname(config-cmap)# match port tcp eq 80
143356
inside
port 80
outside
A
Host A
Host B
port 80
Security
appliance
insp.
insp.
police
inside
port 80
outside
A
Host A
Host B
port 80
insp.
insp.
Security
appliance
143414

Cisco ASA Series Specifications

General

Model	ASA 5505
Interfaces	Varies by model (Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet, etc.)
High Availability	Active/Standby or Active/Active (varies by model)
Power Supply	Varies by model
Form Factor	Varies by model
Operating System	Cisco ASA Software
IPsec VPN	Supported
SSL VPN	Supported
IPS Throughput	Varies by model
