ASR 5000 Hardware Platform Overview
â–€ ASR 5000 Line Cards
â–„ Cisco ASR 5000 Series Product Overview
OL-22938-02
Figure 19. Redundancy Crossbar Car
Table 13. RCC Callout Definitions
Number
Description
1
Card Ejector Levers—Use to insert/remove a card to and from the chassis.
2
Interlock Switch—When pulled downward, the interlock switch notifies the system to safely power down card prior to
removal.
3
Card Level Status LEDs—Show the status of the card. (See Applying Power and Verifying Installation for
definitions).
