Cisco ASR 5000 Series User Manual

ASN Gateway Overview
ASN Gateway in a WiMAX Network ▀
Cisco ASR 5000 Series Product Overview ▄
OL-22938-02
ASN Gateway in a WiMAX Network
In a WiMAX network architecture, each of the entities, Subscriber Station (SS)/Mobile Station (MS), Access Service
Network (ASN) and Connectivity Service Network (CSN) represent a grouping of functional entities.
Each of these functions may be in a single physical device or distributed over multiple physical devices to meet
functional and interoperability requirements. The following figure shows a high-level example of WiMAX network
architecture
Figure 39. WiMAX Network Architecture
WiMAX Base
Station
Internet
Enterprise
ASN Gateway
ASN Gateway
Acess Service Network (ASN)
Another CSN
Another ASN
Home Agent
(HA)
Connectivity Service Network (CSN)
CDMA 2000 1xEV-DO Rev. 0, Rev. A;
UMTS/W-CDMA/LTE/SAE
Authorization
Authentication,
and Accounting
(AAA) Server
WiMAX SS/MS
WiMAX SS/MS
