Cisco ASR 5000 Series User Manual

Session Control Manager Overview
Network Deployments and Interfaces ▀
Cisco ASR 5000 Series Product Overview ▄
OL-22938-02
Network Deployments and Interfaces
SCM in a CDMA2000 Data Network Deployment
Integrated CSCF / A-BG / HA
The SCM is designed to function within a CDMA2000 PDSN network. By combining the SCM with a carrier-class
Home Agent, a number of advantages emerge such as increased performance, distributed architecture, and high
availability. As shown in the figure below, the SCM supports a number of interfaces used to communicate with other
components in an IMS environment and supports the interface used to bridge the CDMA network.
Figure 146. CDMA2000 CSCF/A-BG/HA SCM Deployment Example
BSC/PCF
PDSN
UE
CSCFs
PCRF
Mw
Gm
Dx
(S / I-CSCF)
Sh
(S-CSCF)
HSS
Cx
()S / I-CSCF
SLF
BTS
Tx (P-CSCF / A-BG)
LRF
-CSCFE/I/P/S /
A-BG / HA
OFCS
MI
(E-CSCF)
Rf
Logical Network Interfaces (Reference Points)
Interfaces, used to support IMS in a CDMA network, can be defined within two categories: SIP and DIAMETER. The
SCM incorporates standards-based interfaces for both SIP and DIAMETER network architectures.
