PDN Gateway Overview

▀ Network Deployment(s)

▄ Cisco ASR 5000 Series Product Overview

OL-22938-02

Supported Logical Network Interfaces (Reference Points)

The following figure displays the network interfaces between a PDN Gateway, other E-UTRAN network devices, a

packet data network, and an HSGW in an eHRPD network.

Figure 133. P-GW Interfaces in the E-UTRAN/EPC Network

E-UTRAN

EPC

Internet

Enterprise

S-GW

S5/S8

SGi

PCRF

3GPP

AAA

S6b

Signaling Interface

Bearer Interface

OCS

P-GW

OFCS

Rf / Gz

The P-GW provides the following logical network interfaces in support of eHRPD to E-UTRAN/EPC connectivity:

S5/S8 Interface
