Safety, Electrical, and Environmental Certifications

Safety Certifications ▀

Cisco ASR 5000 Series Product Overview ▄

OL-22938-02

Safety Certifications

The ASR 5000 complies with all safety certifications listed below.

UL60950 - Standard for Safety for Information Technology Equipment, 3rd Edition

European Union EN 60950 (CE Mark)
