MUR Overview

System Requirements ▀

Cisco ASR 5000 Series Product Overview ▄

OL-22938-02

System Requirements

This section identifies the minimum system requirements for MUR.

Important: The hardware required for MUR may vary depending on incoming EDR generation, subscriber

count, and number of gateways.

Sun Microsystems Netra™ X4450 server

Quad-Core Intel Xeon E7340 (2 * 4MB L2, 2.40 GHz, 1066 MHz FSB)

32GB RAM

8 * 300GB 10K RPM SAS disks

Four 10/100/1000 Ethernet ports, 2 PCI-X, 8 PCIe

4 redundant AC power supplies

Intelx64 core 4 socket

Operating Environment:

Sun Solaris 10

ZFS is the recommended file system with two ZFS pools.

One pool with minimal capacity, two disks mirrored for OS only. The remaining disks are to be configured in

one single zpool.
