Cisco ASR 5000 Series User Manual

Technical Specifications
Power Specifications ▀
Cisco ASR 5000 Series Product Overview ▄
OL-22938-02
Power Specifications
The following table provides essential power specifications for the chassis and all associated cards within the system.
Table 104. Chassis Power Requirements
Characteristic
Value
Input Voltage
Maximum range: -40VDC to -60VDC
Nominal range: -48VDC to -60 VDC
TUV Rated Peak Current Load
145A @ -48 VDC
Maximum Peak Power Load
5760W
Chassis Max Power Load
800W
Line Card (rear-installed) Max Power Load
SPIO: 15W
Ethernet 10/100: 13.5W
Ethernet 1000: 10.5W
Quad Gig-E (QGLC): 15W
XGLC: 25W
Optical (ATM/POS OC-3) 23W
Channelized (STM-1/OC-3): 23W
RCC: 20W
Application Card (front-installed) Max Power Load
SMC: 130W
PPC: 325W
PSC: 250W
PSC2: 325W
Estimating Power Requirements
Use the following formula to estimate total power consumption for each deployed chassis.
(Total Application Card Max Power Load) + (Total Line Card Max Power Load) + (Chassis Max Power Load)
Example
The calculation for estimating the power required for an ASR 5000 installation with 3 PSCs, 2 SMCs, 2 SPIOs, 2 RCCs,
and 4 Ethernet 1000 line cards would be:
(250W x 3) + (130W x 2) + ((15W x 2) + (20W x 2) + (13.5W x 4)) + 800W = 1934W
