Cisco ASR 5000 Series - Implementation

Serving GPRS Support Node (SGSN) Overview
Features and Functionality - Basic ▀
Cisco ASR 5000 Series Product Overview ▄
OL-22938-02
Figure 164. MOCN-type Network Sharing
Core Network
Operator A
Core Network
Operator B
Core Network
Operator C
Iu
RNC
Radio Access Network
Operator X
With the MOCN configuration, the SGSN supports the following scenarios:
MOCN with non-supporting UE
MOCN with supporting UE
Implementation
To facilitate network sharing, the SGSN implements the following key features:
Multiple virtual SGSN services in a single physical node.
Sharing operators can implement independent policies, such as roaming agreements.
Equivalent PLMN configuration.
RNC identity configuration allows RNC-ID + MCC-MNC instead of just RNC-ID.
Configuration for network sharing is accomplished by defining:
NRI in the SGSN service configuration mode
PLMN IDs and RNC IDs in the IuPS configuration mode
IMSI ranges in the Operator Policy configuration mode
