Cisco ASR 5000 Series User Manual

ASN Gateway Overview
▀ ASN Call Procedure Flows
▄ Cisco ASR 5000 Series Product Overview
OL-22938-02
To disable this default behavior use the command in the ASN
Gateway Service Configuration Mode. For more information regarding this command, refer to the Cisco Systems
Command Line Interface Reference.
MS Triggered Network Exit
This section describes the procedure of MS Triggered network exit for a WiMAX Subscriber Station (SS) or MS in
normal mode.
The following figure provides a high-level view of the steps involved for network exit of an SS/MS in normal mode.
The following table explains each step in detail.
Figure 46. MS Triggered Network Exit Call Flow
ASN BS
ASN-GW/FA/
Authenticator
MS/SS
DATA
CSN/PDN/
Internet
1
2
CSN HA
H-AAA
Server
3
4
5
6
7
8
9
