ASN Gateway Overview

▀ WiMAX Deployment with Legacy Core Networks

▄ Cisco ASR 5000 Series Product Overview

OL-22938-02

WiMAX Deployment with Legacy Core Networks

ASN Gateway Interoperability with 3GPP Overlay

The following figure shows a typical interoperability scenario between WiMAX and 3GPP legacy networks with

reference points and interfaces.

Figure 63. ASN Gateway with 3GPP Overlay

Wi/

WpWn

ASN

WiMAX Elements

3GPP Network

WiMAX

SS/MS

ASN-GW

CSN

ASN-GW

CSN IWU

3GPP AAA

Server

WAG PDG

3GPP PS

Services

ASN Gateway Interoperability with 3GPP2 Overlay

The following figure shows a typical interoperability scenario between WiMAX and 3GPP2 legacy networks with

reference points and interfaces.
