ASN Gateway Overview

ASN Gateway in a WiMAX Network ▀

Cisco ASR 5000 Series Product Overview ▄

OL-22938-02

Figure 40. ASN Network Reference Model with ASN Gateway

ASN Gateway

ASN

H-AAA

Another CSN

Network Service Privider

(NSP)

Network Access Privider

(NAP)

CSN

Another ASN/

ASN-GW

Connectivity Service Network (CSN)

The Connectivity Service Network (CSN) is a set of network functions that provide IP connectivity services to the

WiMAX subscriber. A CSN provides the following functions:

SS/MS IP address and endpoint parameter allocation for user sessions

Internet access

AAA proxy or server

Policy and admission control based on user subscription profiles

ASN-CSN tunneling support,

WiMAX subscriber billing and inter-operator settlement

Inter-CSN tunneling for roaming

Inter-ASN mobility

Home agent
