Chassis Configurations
The system is designed to scale from a minimum configuration, as shown in the table below, to a fully-loaded redundant
configuration containing a maximum of 48 cards.
ASR 5000 Chassis Hardware Configuration
Note that if Session Recovery is enabled, the minimum number of packet processing cards per chassis increases from
one to four cards. Three packet processing cards are active and one packet processing card is standby (redundant). This
minimal configuration is designed to protect against software failures only. In addition to increased hardware
requirements, Session Recovery may reduce subscriber session capacity, performance, and data throughput.
Important: For Release 9.0, only PDSN and HA are supported on the PPC.
Component
Supported Cisco
Systems Product
Minimum per
Chassis
Minimum for Redundant
Chassis Configuration
Maximum per
Chassis
System Management Card (SMC)
1
2
2
Packet Processor Card (PPC)
(Data application card)
1
2*
14
Packet Services Card (PSC) (Data
application card)
1
2*
14
Packet Services Card 2 (PSC2)
(Data application card)
1
2
14
Switch Processor I/O (SPIO) Card
1
2
2
Redundancy Crossbar Card (RCC)
0
2
2
Power Filter Unit (PFU)
2
2
2
Upper Fan Tray Assembly
1
1
1
Lower Fan Tray Assembly
1
1
1
Line Cards
Fast Ethernet (10/100) Line Card
(FELC)
All
1
2
28**
Gigabit Ethernet Line Card
(GELC)
All
1
2
28**
Quad Gigabit Ethernet Line Card
(QGLC)
All
1
2
28**
10 Gigabit Ethernet Line Card
(XGLC)
All
1
2
14***
Optical Line Card (OLC)
SGSN only
1
2
28**
Optical Line Card 2 (OLC2)
SGSN only
1
2
28**
