Cisco ASR 5000 Series - Fan Tray Assemblies

Technical Specifications
Physical Dimensions ▀
Cisco ASR 5000 Series Product Overview ▄
OL-22938-02
Height
Width
Depth
8.59 in. (21.82 cm)
1.01in. (2.56 cm)
5.24 in. (13.31cm)
Fan Tray Assemblies
Lower Fan Tray
Table 99. Physical Dimensions - Lower Fan Tray
Height
Width
Depth
2.50 in. (6.35 cm)
16.25 in. (41.27 cm)
17.25 in. (43.82 cm)
Upper Fan Tray
Table 100. Physical Dimensions - Upper Fan Tray
Height
Width
Depth
2.875 in. (7.30 cm)
16.25 in. (41.27 cm)
19.375 in. (49.21 cm)
Power Filter Unit
Table 101. Physical Dimensions - 165A Power Filter Unit
Height
Width
Depth
3.6 in. (9.14 cm)
8.25 in. (20.96 cm)
5.12 in. (13.00 cm)
