PDN Gateway Overview

Network Deployment(s) ▀

Cisco ASR 5000 Series Product Overview ▄

OL-22938-02

For more information on the Gy interface and online accounting, refer to Gy Interface Support in the Features and

Functionality - Base Software section of this guide.

PDN Gateway in the E-UTRAN/EPC Network

The following figure displays a simplified network view of the P-GW and how it interconnects with other 3GPP

Evolved-UTRAN/Evolved Packet Core network devices.

Figure 132. P-GW in the E-UTRAN/EPC Network

E-UTRAN

EPC

S-GW

S1-U

S5/S8

S11

Gxc

S1-MME

eNodeB

S6a

MME

PCRF

3GPP

AAA

S6b

SWx

HSS

Signaling Interface

Bearer Interface

OFCS

OCS

Internet

SGi S2b

S2c

Enterprise

P-GW

Trusted/Untristed

Non-3GPP Devices

Rf / Gz
