IP Services Gateway Overview

Service Modes ▀

Cisco ASR 5000 Series Product Overview ▄

OL-22938-02

Figure 115. IPSG Message/Data Flow (RADIUS Snoop Mode)

Mobile

Station

RADIUS

Server

Access Gateway

(GGSN/PDSN/HA)

IPSG

Acct Req

IP Data

Acct Resp

Acct Req

Internet
