Packet Data Interworking Function Overview

Sample Deployments ▀

Cisco ASR 5000 Series Product Overview ▄

OL-22938-02

Figure 119. Mobile IP Session Setup over IPSec

Table 64. Mobile IP over IPSec Call Flow Description

Step

Description

After the MS learns the IP address of the PDIF, the MS and the PDIF/FA exchange IKE_SA_INIT messages to negotiate

an acceptable cryptographic suite.

Default Chapter4
