New In Release 10.0

▀ SCM Features

▄ Cisco ASR 5000 Series Product Overview

OL-22938-02

IPv4-IPv6 Interworking

MSRP is now supported when IPv4-IPv6 interworking is enabled.

IPv6 Support

In addition to supporting IPv4, the SCM supports IPv6 addressing. A CSCF service can be configured with v6 addresses

to support an all v6 network.

Important: For this feature, you may bind a CSCF service to either an IPv4 address or to an IPv6 address, but

not both simultaneously.

The following diagram shows the implementation where CSCF supports only IPv4.

Figure 2. IPv4 Configuration

With IPv6 support, the configuration supported would look like the following diagram. The DNS server could be either

IPv4 or IPv6.
