PDN Gateway Overview

▀ Network Deployment(s)

▄ Cisco ASR 5000 Series Product Overview

OL-22938-02

Figure 131. P-GW Interfaces Supporting eHRPD to E-UTRAN/EPC Connectivity

E-UTRAN

EPC

Signaling Interface

Bearer Interface

Internet

Enterprise

S-GW

S5/S8

SGi

eHRPD

HSGW

S2a

PCRF

S6b

OFCS

OCS

3GPP AAA

P-GW

The P-GW provides the following logical network interfaces in support of eHRPD to E-UTRAN/EPC connectivity:

S5/S8 Interface

This reference point provides tunneling and management between the S-GW and the P-GW. The S8 interface is used for

roaming scenarios. The S5 interface is used for non-roaming.

Supported protocols:
