Cisco ASR 5000 Series Product Overview ▄
Monthly Reports: Usage reporting for the past 30-day period (1st day of the month through the last day
of the month)
Average Reports
Top ―N‖ Reports
Statistical and analytical reports
Bulkstats and KPI reports
The MUR application provides the following reports:
Traffic Analysis Report: The Traffic Analysis report provides the total usage traffic (including uplink and
downlink traffic) details for the following application categories:
Filesharing
Web
IM
VOIP
Standard
Streaming
Tunnel
Gaming
Unclassified
The usage traffic is expressed in terms of megabytes (MB) or Megabits per second (Mbps) and percentage (%).
The traffic can also be in gigabytes (GB) / kilobytes (KB) / bytes depending on the magnitude.
Traffic Distribution Report: The Traffic Distribution report provides the summary of total traffic distribution for
all the protocols application categories over a specified time period. The usage traffic is represented in
GB/MB/KB/Bytes and percentage.
Active Flow Count Report: The Active Flow Count report provides the details of traffic distribution flow count
against the different application categories. This report also provides the summary of total number of flows in
the EDR records.
Unique Subscriber Hits Report: The Unique Subscriber Hits report provides an overview of the usage patterns of
the entire subscriber population per protocol, for example, how many people are actually using VoIP.
TopN versus Total Traffic Report: This report provides the summary of total usage traffic and Top N subscriber
traffic for all the protocols over a specified time period. The usage traffic is represented in GB/MB/KB/Bytes
and packets.
TopN Subscribers Report: The TopN Subscribers report simply counts the number of bytes per subscriber for
different time intervals. It displays the top 10/100/1000 subscribers for each hour (or just for the busy hour) and
for each day/week/month/year. This report is displayed for all configured gateways.
After identifying the total amount of transferred data per subscriber, and identifying the top users, to
understand the protocol and services breakdown for each subscriber, this report allows listing the different
applications used by the top 10/100/1000 subscribers.
TopN VCD Subscribers Report: The TopN VCD Subscribers report displays the top N subscribers based on their
voice usage (voice duration) for Yahoo, MSN and Skype voice protocols. The summary report displays the
voice summary (voice duration) for VoIP category.
HTTP EDR based Reports: The MUR application parses HTTP EDRs and generates the following reports based
on the EDRs:
