MUR Overview

Distributed Architecture of MUR ▀

Cisco ASR 5000 Series Product Overview ▄

OL-22938-02

Figure 196. MUR with RDPs in Distributed Model

Master inPilot

RDP 1 RDP 3RDP 2

JSON RPC

SFTP

Gateway 1 Gateway 2 Gateway 3 Gateway 4 Gateway 5 Gateway 6

Each of the registered RDPs will form a new region. RDP region can be a child of the root of the MUR (NOC) or can be

the child of another region. However, all the gateways associated with a RDP will always be the children of RDP

region.

Important: Only single MUR can communicate with an RDP simultaneously.
