ASR 5000 Hardware Platform Overview

▀ ASR 5000 Application Cards

▄ Cisco ASR 5000 Series Product Overview

OL-22938-02

Figure 14. SMC Callout Descriptions

Table 7. System Management Card (SMC)

Item

Description

Card Ejector Levers —Use to insert/remove card to/from chassis.

Interlock Switch —When pulled downward, the interlock switch notifies the system to safely power down card prior to

removal.

Card Level Status LEDs—Show the status of the card. (See Applying Power and Verifying Installation for definitions).
