Viewing General Mesh Network Details
To view general mesh network details, enter these commands:
•
show mesh env {summary | AP_name}—Shows the temperature, heater status, and Ethernet status for
either all access points (summary) or a specific access point (AP_name). The access point name, role
(RootAP or MeshAP), and model are also shown.
◦ The temperature is shown in both Fahrenheit and Celsius.
◦ The heater status is ON or OFF.
◦ The Ethernet status is UP or DOWN.
The battery status appears as N/A (not applicable) in the show mesh env AP_name
status display because it is not provided for access points.
(Cisco Controller) > show mesh env summary
AP Name Temperature(C/F) Heater Ethernet Battery
------------------ ---------------- ------ -------- -------
SB_RAP1 39/102 OFF UpDnNANA N/A
SB_MAP1 37/98 OFF DnDnNANA N/A
SB_MAP2 42/107 OFF DnDnNANA N/A
SB_MAP3 36/96 OFF DnDnNANA N/A
(Cisco Controller > show mesh env SB_RAP1
AP Name.......................................... SB_RAP1
AP Model......................................... AIR-LAP1522AG-A-K9
AP Role.......................................... RootAP
Temperature...................................... 39 C, 102 F
Heater........................................... OFF
Backhaul......................................... GigabitEthernet0
GigabitEthernet0 Status.......................... UP
Duplex....................................... FULL
Speed........................................ 100
Rx Unicast Packets........................... 988175
Rx Non-Unicast Packets....................... 8563
Tx Unicast Packets........................... 106420
Tx Non-Unicast Packets....................... 17122
GigabitEthernet1 Status.......................... DOWN
POE Out........................................ OFF
Battery.......................................... N/A
Note
• show mesh ap summary—Revised to show the CERT MAC field that shows a MAC address within
an AP certificate that can be used to assign a username for external authentication.
(Cisco Controller) > show mesh ap summary
AP Name AP Model BVI MAC CERT MAC Hop Bridge Group Name
------- --------------- ----------------- ---------------- ---- -----------------
R1 LAP1520 00:0b:85:63:8a:10 00:0b:85:63:8a:10 0 y1
R2 LAP1520 00:0b:85:7b:c1:e0 00:0b:85:7b:c1:e0 1 y1
H2 AIR-LAP1522AG-A-K9 00:1a:a2:ff:f9:00 00:1b:d4:a6:f4:60 1
Number of Mesh APs............................... 3
Number of RAP................................... 2
Number of MAP................................... 1
Cisco Mesh Access Points, Design and Deployment Guide, Release 7.3
194 OL-27593-01
