Cisco Mesh Access Points User Manual

• show mesh path—Displays MAC addresses, access point roles, SNR ratios (dBs) for uplink and downlink
(SNRUp, SNRDown) and link SNR for a particular path.
(Cisco Controller) > show mesh path mesh-45-rap1
AP Name/Radio Mac Channel Snr-Up Snr-Down Link-Snr Flags State
----------------- ------- ------ -------- -------- ------ -------
mesh-45-rap1 165 15 18 16 0x86b UPDATED NEIGH PARENT BEACON
mesh-45-rap1 is a Root AP.
• show mesh neighbor summary—Displays summary information about mesh neighbors. Neighbor
information includes MAC addresses, parent-child relationships, and uplink and downlink (SNRUp,
SNRDown).
(Cisco Controller) > show mesh neighbor summary ap1500:62:39:70
AP Name/Radio Mac Channel Snr-Up Snr-Down Link-Snr Flags State
mesh-45-rap1 165 15 18 16 0x86b UPDATED NEIGH PARENT BEACON
00:0B:85:80:ED:D0 149 5 6 5 0x1a60 NEED UPDATE BEACON DEFAULT
00:17:94:FE:C3:5F 149 7 0 0 0x860 BEACON
After review of the show mesh commands above, you should be able to see the
relationships between the nodes of your network and verify the RF connectivity by
seeing the SNR values for every link.
Note
• show mesh ap tree—Displays mesh access points within a tree structure (hierarchy).
(Cisco Controller) > show mesh ap tree
R1(0,y1)
|-R2(1,y1)
|-R6(2,y1)
|-H2(1,default)
Number of Mesh APs............................... 4
Number of RAP................................... 1
Number of MAP................................... 3
Viewing Mesh Access Point Details
To view a mesh access point’s configuration, enter these commands:
•
show ap config general Cisco_AP—Displays system specifications for a mesh access point.
(Cisco Controller) > show ap config general aps
Cisco AP Identifier.............................. 1
Cisco AP Name.................................... AP5
Country code..................................... US - United States
Regulatory Domain allowed by Country............. 802.11bg:-AB 802.11a:-AB
AP Country code.................................. US - United States
AP Regulatory Domain............................. 802.11bg:-A 802.11a:-N
Switch Port Number .............................. 1
MAC Address...................................... 00:13:80:60:48:3e
IP Address Configuration......................... DHCP
IP Address....................................... 1.100.163.133
...
Primary Cisco Switch Name........................ 1-4404
Primary Cisco Switch IP Address.................. 2.2.2.2
Secondary Cisco Switch Name...................... 1-4404
Secondary Cisco Switch IP Address................ 2.2.2.2
Tertiary Cisco Switch Name....................... 2-4404
Cisco Mesh Access Points, Design and Deployment Guide, Release 7.3
OL-27593-01 195
Checking the Health of the Network
Viewing Mesh Access Point Details
