Cisco Small Business 200 Series Administration Guide

Administration: Discovery
Configuring CDP
Cisco Small Business 200 Series Smart Switch Administration Guide 107
9
• No. of Neighbors—Number of neighbors detected.
The bottom of the page has four buttons:
• Copy Settings—Select to copy a configuration from one port to another.
• Edit—Fields explained in Step 2 below.
• CDP Local Information Details—Takes you to the Administration > Discovery - CDP > CDP Local
Information page.
• CDP Neighbor Information Details—Takes you to the Administration > Discovery - CDP > CDP
Neighbor Information page.
STEP 2 Select a port and click Edit.
This page provides the following fields:
• Interface—Select the interface to be defined.
• CDP Status—Select to enable/disable the CDP publishing option for the port.
NOTE The next three fields are operational when the device has been set up to send traps to the
management station.
• Syslog Voice VLAN Mismatch—Select to enable sending a SYSLOG message when a voice VLAN
mismatch is detected. This means that the voice VLAN information in the incoming frame does not
match what the local device is advertising.
• Syslog Native VLAN Mismatch—Select to enable sending a SYSLOG message when a native VLAN
mismatch is detected. This means that the native VLAN information in the incoming frame does not
match what the local device is advertising.
• Syslog Duplex Mismatch—Select to enable sending a SYSLOG message when duplex information
mismatch is detected. This means that the duplex information in the incoming frame does not match
what the local device is advertising.
STEP 3 Enter the relevant information, and click Apply. The port settings are written to the
Running Configuration.
